Ultra Slim 0-10v LED Dimmer TV Backlight 24v 200W For LED Ceiling Fan And Strip IP67 Rate

Name: Ultra Slim 010v LED Dimmer TV Backlight 24v 200W For LED Ceiling Fan And Strip IP67 Rate
Brand: KSPOWER
Price: 14.58 USD

China Ultra Slim 0-10v LED Dimmer TV Backlight 24v 200W For LED Ceiling Fan And Strip IP67 Rate factory

Place of Origin : Guangdong, China

Brand Name : KSPOWER

Model Number : KSHL

Certification : UL/cUL/CE/TUV-GS/RoHS/Class2

MOQ : 5 pieces

Price : $14.58-59.88/pieces

Warranty(Year) : 5-Year

Lighting solutions service : Lighting and circuitry design

Output Power : 100w 120w 150w 200w

Output Type : PWM

Input Voltage : 100-277VAC

Output Frequency : 50/60Hz

Output Current : 2.08A-16.66A

Product Name : 100W-200W Dimming led driver

Material : Aluminum Case

Warranty : 5 years

Protection : OCP, OVP, SCP, OTP

IP Rate : IP65:IP67

Efficiency : ≥91%

Power : 100w 120w 150w 200w

Output : 12V 24V

Application : LED Strip Light,Pendants, Linears,Cove Lights

Contact Now

Ultra Slim 0-10v LED Dimmer TV Backlight 24v 200W For LED Ceiling Fan And Strip IP67 Rate

Products Description

0-10v led tv backlight driver dc 12v 24v 100w 120w 150w 200w ultra slim led driver 12v driver for led ceiling fan

Input Voltage	100~277V AC 47~63Hz
Power Factor	PF≧0 98/115VAC, PF≧0 95/230VAC, PF≧0.9/277VAC, 80% with load
NO.	KSHL
Output Voltage	12volts/ 24volts/ 36volts/48volts
Rated Current	0.62A-16.66A
Rated Power	30w 40w 60w 80w 96w 100w 120w 150w 180w 200w 240w 300w 320w
Certification	UL/cUL/CE/TUV-GS/RoHS/FCC/Class2

Features:
− Universal AC input voltage 100-277VAC − Efficiency up to 91% − Built-in active PFC function − Single channel & constant voltage mode and PWM style output − Protection: OCP, OVP, SCP, OTP − Limited Power Source − cUL, RoHS, CE, ENEC, GS, Class P, SAA Approved − Function options: 1. Non-dimmable 2. Triac/Phase-cut Dimmable 3. 4 in 1 dimmable (0-10V,1-10V,PWM,resistance) 4. 5 in 1 dimmable (0-10V,1-10V,TRIAC,PWM,resistance) − Typical lifetime > 50000 hours − 5 years warranty − Available with or without integrated Junction Box − IP65 IP67 Rated Enclosure for Indoor and Outdoor Use − Wiring Compartments with Knock-Outs for Clean and Easy Installation

Note:Any custom label/package/case is acceptable, provide OEM and ODM service

Show Details

NOW,GET MORE INFORMATIONS OF US !

Company Profile

Working Room

Exhibition

Certifications

Applications

Product packaging

1.Sample is available.

2.Shipping method: available for express DHL/UPS/FedEx/TNT, Land, Ocean and others.

3. for 60W power adapter : each one put in one small inner brown box, then 50 pcs put in one standard carton.

Package	Piece/Carton(pcs)	Piece Weight(KG)
OEM package	50	0.26
Dimension/Brown Box(mm)	Dimension/Carton(mm)	Gross Weight/Carton(KG)
1558535	455370175	14
